FD4010-N
40x40x10mm
*Airflow: 5.08~8.71 CFM
*Static Pressure: 1.69~5.08 mm-H2O
*Blade / Housing:
Plastic Material UL 94V-0 P.B.T.
*Lead Wire: UL1007 #26 AWG
*Weight: 13.6 g
| no. | Model | bearing | Rated Voltage (VDC) |
operating voltage range (VDC) |
Speed (RPM) |
Max. Airflow (CFM) |
Max. Static Pressure (mm-H2O) |
Current (mA) |
Life at 40°C L10 (Hour) |
Noise Level dB(A) |
Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | FD054010LL-N | L | 5 | 4~5.5 | 5000 | 5.08 | 1.69 | 70 | 50000 | 17.5 | 13.6 |
| 2 | FD054010ML-N | L | 5 | 4~5.5 | 6000 | 6.09 | 2.64 | 120 | 50000 | 21.5 | 13.6 |
| 3 | FD054010HL-N | L | 5 | 4~5.5 | 7500 | 7.69 | 3.64 | 180 | 50000 | 25.0 | 13.6 |
| 4 | FD124010LB-N | 2B | 12 | 8~13.2 | 5000 | 5.08 | 1.69 | 25 | 80000 | 17.5 | 13.6 |
| 5 | FD124010MB-N | 2B | 12 | 8~13.2 | 6000 | 6.09 | 2.64 | 40 | 80000 | 21.5 | 13.6 |
| 6 | FD124010HB-N | 2B | 12 | 7~13.2 | 7500 | 7.69 | 3.64 | 60 | 75000 | 25.0 | 13.6 |
| 7 | FD124010EB-N | 2B | 12 | 7~13.2 | 8500 | 8.71 | 5.09 | 80 | 65000 | 28.0 | 13.6 |
| 8 | FD124010LL-N | L | 12 | 7~13.2 | 5000 | 5.08 | 1.69 | 30 | 50000 | 17.5 | 13.6 |
| 9 | FD124010ML-N | L | 12 | 7~13.2 | 6000 | 6.09 | 2.64 | 50 | 50000 | 21.5 | 13.6 |
| 10 | FD124010HL-N | L | 12 | 7~13.2 | 7500 | 7.69 | 3.64 | 75 | 50000 | 25.0 | 13.6 |
2B : 2-ball bearing BS : 1-ball 1-slee bearing L : Sintetico bearing S : Sleeve Bearing
